PROJECT DETAILS
| Product name: | 2.4G Omni-directional RFID reader |
|---|---|
| Product model: | MR3102E |
| Product category： | 2.4G RFID READER |
Product overview
- MR3102E Omni-directional reader suit for “non-directional identify” .MR3102E applying in far distance, quick identification, meeting the special demand of identification, can identify, track and orientate more than 100 active tags simultaneity.
Product parameters
- Items Parameter
- Physical property
- matrerial ABS
- dimension 92*Φ110mm
- weight 200g
- way to install wall-mounted, ceiling fixed
- 2.4G RF feature
- Identify type Omni-directional, 360 degree covered
- Signal modulation mode GFSK
- Traffic rate 1Mbit/s
- Working frequency 2440MHz
- MAX receive sensitivity -90dbm
- Antenna Gain 2dbi，dual polarization
- Communication interface
- RS232 (TCP to RS232 converter needed) Baud rate：115200bps；data bits：8；stop bit：1；check bit：N
- RJ45 10/100self-adaption
- Power supply features
- Working current 350mA
- Working voltage 9V DC
